Cling Film Packaging Machine

Operating Procedures

1. Select the appropriate packaging data and label data (pre‐set storage)
2. Place product in the bracket position, will automatically weighing at the same time
3. Take out the packaged finished product and gently press the heating plate
4. Manually paste the printed label onto the packaged item.

Features:

1. Efficient packaging
With an average of 15 packs per minute, the packaging efficiency is about three times that of the manual.

2. One machine multi‐energy
It combines the functions of automatic packaging, weighing and printing labels to save costs.

3. Good packaging effect
Compared with labor, the packaging is more firm and beautiful, which helps to enhance the brand value. Can be packed with or without trays, and is suitable for trays of various shapes (such as round, hexagon, etc.)

5. High‐end material selection
The whole machine adopts stainless steel to adapt to the corrosive environment such as high humidity; foreign similar equipment only partially or completely does not use stainless steel, and is easily corroded under harsh environment.

6. Comfortable operation
The interface design is simple, fast response, meet us operating habits; compared to foreign equipment, low noise, With special mute treatment, it is more comfortable to use.

7. Exquisite workmanship
Overall welding processing, equipment stability is better than similar equipment abroad.

8. Service quality
Independent research and development production, rapid response, after‐sale coverage

9. Wide choice of consumables
Applicable to all kinds of plastic wrap (PVC/PE), domestic imports can be used to save costs; some foreign equipment can only use imported plastic wrap.

Cling FILM packaging MACHINE

Contact us Now

573-539-6511

Watch Our Automatic Cling Film Machine in Action

Specifications:

Packing
Speed‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐15bag / min
Package length‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐80—350mm
Package width‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐80—230mm
Package height‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐10—150mm
Package weight‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐100g—3kg
Cling film width‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐350‐500mm

Component
Touch screen‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐10.2 Inch TFT color touch screen (screen ratio16:9 )
Display resolution‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐1024*600
Power supply‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐220V / 50HZ
Power‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐1860W
Working humidity‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐10‐90%RH
Cylinder ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐SMC
Low voltage electrical appliance ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐Schneider
Machine material ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐stainless steel
Dimensions‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐840*888*1415mm

Label Parameter
Label Type‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Thermal Label
Label paper width ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐15‐110mm
Label paper thickness ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐0.06 mm~0.2 mm
Print resolution ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐203dpi (8 dots/mm)
Label color ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ black and white
The maximum diameter of the paper roll ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 127mm
Paper rolling strip heart diameter ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 25.4mm

The UNI-CBF-15A Automatic Cling Film Packaging Machine is one of the most reliable and feature rich Cling machines on the market. It offers exceptional performance, virtually no maintenance and an extremely low Total Cost of Ownership in a compact, easy to use system.

Be sure to check out all the amazing features below as well as the video showing it in action.
